DAWSON/OEM
DSVS-A
0.5-50Ton
Availability: | |
---|---|
Quantity: | |
500kg 1000kg 1500kg 2000kg 3000kg 5000kg 10000kg 20000kg 30000kg 50000kg Manual Chain Block, Hand Chain Hoist for Lifting
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory
Introduction
Compact design, low headroom for wider usage
High precision machining gears with higher strength, and better toughness
High precision sealed bearing with lighter hand force and higher mechanical efficiency
Impact resistant gear cover, improving the strength and hardness
Double pawls brake system - reinforced pawl, ratchet disc and brake Disc
Double high precision CNC machining load chain guides
Dust cover on brake system can effectively prevent rain and mortar intrusion
Engineering optimized hand chain wheel groove and unique curled edge for the hand cover, preventing hand chain stack in fast operation
High quality alloy steel forging hook
T80 load chain with high precision, high strength and chain strength up to 1000N/m2
High strength chain end connection, with 2.5 times safety factor
Super robust, much higher than 1500 cycles EN 13157 endurance testing
Model | Capacity (T) | Standard lift (m) | Running test (T) | Effort required to lift max load(N) | No. of falls of load chain | Load chain diameter(mm) | Dimension(mm) | Net weight(kg) | |||
A | B | D | H | ||||||||
DSVS-A-0.5T | 0.5 | 2.5 | 0.75 | 300 | 1 | 6 | 137 | 137.5 | 35 | 270 | 8.4 |
DSVS-A-1T | 1 | 2.5 | 1.5 | 330 | 1 | 6 | 162 | 146.5 | 35.5 | 317 | 11 |
DSVS-A-1.5T | 1.5 | 2.5 | 2.25 | 360 | 1 | 8 | 183 | 170 | 45 | 399 | 16.2 |
DSVS-A-2T | 2 | 3 | 3 | 365 | 1 | 8 | 194 | 170 | 42.5 | 414 | 18.5 |
DSVS-A-3T | 3 | 3 | 4.5 | 385 | 2 | 8 | 220 | 170 | 50 | 465 | 25.6 |
DSVS-A-5T | 5 | 3 | 7.5 | 435 | 2 | 10 | 288 | 191 | 64 | 618 | 42.8 |
DSVS-A-10T | 10 | 3 | 15 | 435 | 4 | 10 | 384 | 195 | 85 | 798 | 79.5 |
DSVS-A-20T | 20 | 3 | 30 | 435*2 | 8 | 10 | 625 | 209 | 110 | 890 | 193 |
DSVS-A-30T | 30 | 3 | 45 | 435*2 | 12 | 10 | 691 | 312 | 110 | 1380 | 220 |
DSVS-A-50T | 50 | 3 | 75 | 435*2 | 22 | 10 | 958 | 496 | 170 | 2578 | 1092 |
Standard Setting: T(80) Load Chain Black Tempered Load Chain Zinc Plated Hand Chain Stamping Safety Latch Low Maintenance and Low Friction Bushing | Optional Setting: Overload Protection(OLP) Zinc Plated Load Chain V(100) Load Chain Thrust Bearing on Bottom Hook Thicken Stamping Safety Latch High Precision Caged Roller Bearings |
Chain Hoist is widely used manual hoisting machinery which is easy to use and carry. It can be used in factory, mine, agriculture, electricity, construction site, wharf and dock. And it can also be used in installing of machinery, lifting, loading and unloading in the ware house, especially suitable to be used in the open air and the place without power source.
Welcome to buy the newest and competitive price DAWSON DSVS-A Chain Block from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.
Products Details Show:
DAWSON manual chain hoists are commonly known as chain blocks and are designed for heavy duty lifting and materials handling operations. Chain blocks raise and lower loads by pulling on the hand chain. Chain blocks can be of single or double fall configurations depending on the capacity of the block.
Application of Chain Hoist:
Factory & Package Show:
